Automatic Online Offset Ink Printing Machine

Send Inquiry

Request To Call Back

Automatic Online Offset Ink Printing Machine

Get a Price/Quote

MOQ : 1 Unit

Automatic Online Offset Ink Printing Machine Specification

Diameter
Printing cylinder: 250 mm

Torque
High efficiency servo motor drive

Phase
Three Phase

Shape
Rectangular machine frame

Product Type
Automatic Online Offset Ink Printing Machine

General Use
Commercial printing for packaging, labels, brochures, magazines, and other paper products

Material
High-grade steel & alloy

Type
Sheet-fed offset printing

Capacity
5000-10000 sheets per hour (depending on model and paper type)

Weight (kg)
8500

Computerized
Yes

Automatic
Yes

Touch Screen
Yes

Control System
PLC with digital operator interface

Surface Treatment
Powder coated and painted structure for corrosion resistance

QC System
Integrated online inspection system

Tolerance
0.1 mm printing accuracy

Drawing
Layout drawing provided on request

Voltage
380V/3 Phase/50Hz

Dimension (L*W*H)
5200 x 2500 x 2100 mm

Feature
High speed, multi-color printing, quick make-ready, in-line varnishing

Color
Customizable (Standard: Blue-Gray)

Max Printing Area
1020 x 710 mm

Safety Features
Emergency stop, safety interlocks, overload protection

Operator Requirement
1-2 persons

Drying System
Infrared and hot air dryer integrated

Noise Level
78 dB

Operating Temperature Range
10C - 40C

Min Paper Size
340 x 480 mm

Lubrication
Automatic centralized oil lubrication

Number of Colors
4 to 6 color stations

Paper Thickness Range
0.06-0.6 mm

Power Consumption
Approx. 28 kW

Max Paper Size
1040 x 720 mm

Feeding System
Automatic suction feeder

Registration System
Automatic optical registration

Automatic Online Offset Ink Printing Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
30 Days

Main Domestic Market
All India

Automatic Online Offset Ink Printing Machine About

Discover the resplendent performance of the Automatic Online Offset Ink Printing Machine, a top-rated solution engineered with lofty precision for commercial printing needs. Access 4 to 6 customizable color stations, capable of handling grandiose paper sizes up to 1040 x 720 mm with meticulous accuracy (0.1 mm). The robust design integrates advanced features like infrared and hot air drying, computerized PLC touch-screen controls, and an automatic suction feeder. Its powder-coated structure, high-grade steel build, and centralized lubrication system ensure enduring reliability for packaging, brochures, labels, and beyond.

Versatile Usage and Advanced Features for Commercial Excellence

This grandiose offset printing machine is a powerhouse for commercial print applications including packaging, brochure, label, and magazine production. Designed for sheet-fed operation, it features a lofty, multi-color capability with in-line varnishing for a superior finish. Usability is streamlined by the automatic feeding system, infrared/hot air dryer, and a resplendent digital operator interface, delivering both efficiency and precision. It's ideal for high-speed, high-volume usage in any resplendent printing environment demanding quality and reliability.

Certifications, Supply Ability & Quick Delivery: Always Ready for You

Our offset machines are certified to meet industry standards, with documented layouts available upon request. With stock ready for immediate dispatch and scalable supply options, you'll receive your machine in a timely manner. Competitive asking prices and excellent market value make this a compelling investment. Delivery times are minimized with streamlined logistics-prioritizing both speed and safety. Secure your order today and elevate your printing operations with industry-leading technology and support.

FAQ's of Automatic Online Offset Ink Printing Machine:

Q: How many operators are required to manage the Automatic Online Offset Ink Printing Machine?

A: Typically, only 1 to 2 trained operators are needed due to its advanced automation, user-friendly touch-screen controls, and efficient registration systems.

Q: What specific industries benefit most from this printing machine's capabilities?

A: This machine is ideal for commercial printing operations, especially those producing packaging, brochures, labels, magazines, and other high-volume paper products.

Q: How does the integrated drying system enhance production speed and quality?

A: The infrared and hot air dryer works in tandem to ensure quick ink curing, minimizing downtime between prints and maintaining a grandiose print quality across a range of paper thicknesses.

Q: What safety features make this machine reliable in daily operation?

A: It includes emergency stop mechanisms, safety interlocks, and overload protection to guarantee safe, dependable usage throughout extended print runs.

Q: Where can I request a layout drawing or customized color options for the machine?

A: You can contact the supplier or manufacturer directly to request layout drawings, and to discuss customizable color options to match your workspace needs.
